TOOLHOLDER MVVN N 2020 K16-K
212289100 | SUPORTE MVVN N 2020 K16-K
Product data
Operation type (CTPT)
External Turning
Cutting edge count (CEDC)
4
Hand (HAND)
N
Shank width (B)
20 mm
Shank height (H)
20 mm
Functional height (HF)
20 mm
Functional length (LF)
125 mm
Functional Width (WF)
10 mm
Head length (LH)
43 mm
Prog. Stocks
Yes
* cutting tool parameters according to ISO 13399. Read more here
Spare parts
ALLEN KEY SS20
Article code
290020300
Reference
SS20
ALLEN KEY SS30
Article code
290038400
Reference
SS30
LOCK PIN BS05000
Article code
290054400
Reference
BS05000
SCREW F0602900
Article code
290062200
Reference
F0602900
